Know the field before the first point.
Teams start at the blue boundary bases on the left and right. Home bricks sit inside the field as cover. Every A-half position has a matching B-half bunker, with two shared bricks on the 50.
Control Mid
M1 stages the advance; M2 and W offer different ways to pressure the middle. Two shared bricks interrupt direct lanes without forming a continuous wall.
Work the Dorito arc
D1 through D3 bend toward the central fight. Upper pins and cakes support switches between the arc and Mid.
Counter through Snake
S0 leads to E, S1, the Hook, S2 and S3. Separate guard positions support movement. Opposing tips leave a nominal 10-foot gap.
Buy the bunker set.
Each linked name opens its AIRUPS product page. These quantities cover the entire field; do not double them.
| Manufacturer product | Qty | Ground footprint | Height | Unit USD | Extended USD |
|---|---|---|---|---|---|
| Large Brick ↗ | 6 | 5 x 2.5 ft | 6 ft | $157 | $942 |
| Tall Can ↗ | 4 | 4 ft diameter | 6.5 ft* | $155 | $620 |
| Aztec - 5 ft Tall ↗ | 6 | 5 ft x 40 in | 5 ft | $208 | $1,248 |
| Pin ↗ | 6 | 3 ft diameter | 5 ft | $127 | $762 |
| Small Dorito ↗ | 8 | Not published | Listed as 5 ft Dorito | $179 | $1,432 |
| Mini W ↗ | 4 | 8 ft x 20 in | 5 ft | $164 | $656 |
| Short Cake ↗ | 8 | 3 ft diameter | 40 in | $110 | $880 |
| Snake Beam ↗ | 8 | 10 ft x 20 in | 28 in | $160 | $1,280 |
| 50 bunkers / listed bunker-only subtotal | $7,820 | ||||
Listings checked October 25, 2026. Prices may change. Shipping, tax, logos and customization are excluded. This is an individual-product list, not an AIRUPS bundle or endorsed manufacturer field package.
Equipment outside this bunker list
A complete venue also needs a suitable playing surface, protective netting and supports, start bases/buzzers, boundary marking, compatible anchors, inflation equipment, repair supplies, air supply and appropriate staging and spectator areas. Quantities depend on the site and supplier. No infrastructure allowance is included.
Place every bunker precisely.
Stand on the spectator side. The far-left corner is (0, 0). X increases right; Y increases toward you. Every value is in feet, measured to the center of the ground footprint. A ten-foot square equals one grid step.
Start A: (0, 60). Start B: (150, 60). Midfield: X = 75. Mirror formula: B-X = 150 − A-X; Y stays unchanged.
| Code | Bunker model | A center (X, Y) | B center (X, Y) | Position |
|---|---|---|---|---|
| H | Large Brick | (16, 60) | (134, 60) | Home brick |
| B1 | Aztec - 5 ft Tall | (13, 32) | (137, 32) | Upper rear support |
| B2 | Aztec - 5 ft Tall | (13, 88) | (137, 88) | Lower rear support |
| UE | Tall Can | (24, 27) | (126, 27) | Upper entry |
| LE | Tall Can | (24, 93) | (126, 93) | Lower entry |
| I1 | Short Cake | (26, 63) | (124, 63) | Inner entry cake |
| U1 | Pin | (32, 44) | (118, 44) | Upper switch pin |
| A | Aztec - 5 ft Tall | (40, 23) | (110, 23) | Upper arc Aztec |
| D1 | Small Dorito | (36, 12) | (114, 12) | Dorito approach |
| D2 | Small Dorito | (59, 16) | (91, 16) | Dorito advance |
| D3 | Small Dorito | (64, 29) | (86, 29) | Dorito forward |
| U2 | Short Cake | (51, 33) | (99, 33) | Upper support cake |
| M1 | Large Brick | (40, 55) | (110, 55) | Mid staging brick |
| M2 | Small Dorito | (59, 48) | (91, 48) | Mid forward Dorito |
| W | Mini W | (57, 64) | (93, 64) | Inner Mini W |
| IP | Pin | (61, 74) | (89, 74) | Inner pin |
| SG | Pin | (39, 80) | (111, 80) | Snake guard |
| L1 | Mini W | (49, 86) | (101, 86) | Lower Mini W |
| S0 | Snake Beam | (34, 110) | (116, 110) | Snake approach |
| E | Short Cake | (39, 105) | (111, 105) | Snake entry cake |
| S1 | Snake Beam | (45, 105) | (105, 105) | Snake entry beam |
| Hook | Snake Beam | (53.904, 101.876) | (96.096, 101.876) | Diagonal snake connector |
| S2 | Short Cake | (59, 97.8) | (91, 97.8) | Snake knuckle cake |
| S3 | Snake Beam | (65, 97.8) | (85, 97.8) | Snake forward tip |
| 50-U | Large Brick | (75, 36) · shared | Upper midfield blocker | |
| 50-L | Large Brick | (75, 78) · shared | Lower midfield blocker | |
A- and B- prefixes identify starting halves, for example A-M1. Call the actual occupied bunker after crossing midfield. Hook decimals describe geometry, not required survey tolerance; fit inflated pieces symmetrically.
Build and orient the field.
Mark the rectangle
Mark a 150 x 120 ft playing boundary. Set (0, 0) at the far-left corner from the spectator side. X runs right; Y runs toward spectators. Both diagonals should measure approximately 192.094 ft. Mark the 10 ft grid and the X = 75 midfield line.
Set starts, midfield, then one half
Set base centers at (0, 60) and (150, 60). Place shared bricks at (75, 36) and (75, 78). Place A-half centers using the table, then mirror to B: X-B = 150 - X-A. The field dimensions are the playing boundary, not the net-to-net footprint.
Orient the upright cover
Bricks, Aztecs and Mini Ws have their published width parallel to X and depth parallel to Y. Cylinders need no rotation. Aim A-half Dorito triangular-base apexes toward +X and B-half apexes toward -X. Confirm Dorito ground dimensions before final stakeout.
Assemble the hook snakes
Use eight straight 10 ft AIRUPS Snake Beams. S0: A -45 degrees, B +45 degrees. Hook: A -38.66 degrees, B +38.66 degrees. S1 and S3 are horizontal. Negative angles rise toward Y = 0 as you move right. Hook is a straight beam laid diagonally, not the separate Angle Beam product. E and S2 are short cakes. Opposing S3 tips leave a nominal 10 ft gap.
Fit, secure and record
Inflate before fitting touching pieces. Follow manufacturer and venue requirements for anchoring and protective infrastructure. Apply any fitting adjustment identically on both halves. Record the installed setup. Changes to the published geometry should receive a new version.
Publish, print or rebuild.
Use the SVG for a crisp website graphic, PNG for sharing, PDF for setup, or CSV/JSON to recreate the layout.
Website handoff: upload this HTML and the accompanying files into the same directory. The layout is embedded; there are no external fonts, libraries or scripts.
